EPS molded corner protectors

DESCRIPTION OF MOLDED CORNER PROTECTORS

Range of molded corner protectors for the protection of 2 or 3-sided corners, manufactured with expanded polystyrene EPS foam, commonly known in Spain as Porexpan.

We have a wide range of models for 3-sided corners, e.g. for cabinets, as well as for 2-sided corners, e.g. for table tops, and 2-sided corners, e.g. for furniture side corners.

BENEFITS OF CORNER PROTECTORS

Our EPS expanded polystyrene molded corner pieces for packaging offer the advantage that their price/impact absorption ratio is the highest among all packaging materials.

Its low cost is due to the fact that it is manufactured with molds, already standardized for each model, which allows a mass production that lowers costs.

There are pyramid-shaped models, which can be fitted together and take up little space, both in the warehouse and in the packaging assembly area.

EPS molded corner protectors are a highly environmentally friendly material, as they are made from a high percentage of recycled material. In addition, it is only 2% plastic, the rest is air, which allows a high level of protection with a minimum use of plastic.

Its wide use makes it easier and easier to take it for recycling. Its recycling is very clean as it does not require water or high energy consumption, often it is only necessary to shred it and it can be used in e.g. insulation boards.

PROPERTIES OF CORNER PROTECTORS

It is not multi-impact, so its use will be restricted to logistics with little change of hands. 100% recyclable, reusable and non-polluting material.

It is a material that does not pick up humidity, nor does it affect or scratch the surfaces in contact. Normally the corner protectors are manufactured with a density of 20 kg/m3, although depending on its use it could be made in higher densities.

It is always white.

APPLICATIONS OF CORNER PROTECTORS

Its main use in packaging is in the furniture sector, but also in POP or displays and objects of regular shapes.

Do you want to know the price of this product?

Request information free of commitment of EPS molded corner protectors

Technical Data of EPS molded corner protectors

EPS molded corner protectors

Ref. Description Interior measure Exterior measure Units per bag Scheme
R003 Molded corner protector REF. 100-20 72x72x20 mm 100x100x53 mm 288 Falta imagen y ALT
R004 Angular molded corner protector REF. A-15 49×49 mm 65x65x600 mm 200
R005 Angular molded corner protector REF. A-30 55×55 mm 85x85x700 mm 96
R008 Molded corner protector REF. 100-10 72x72x10 mm 100x100x30 mm 480
R011 Molded corner protector REF. 120-15 100x100x15 mm 120x120x43 mm 336
R012 Molded corner protector REF. 120-25 100x100x25 mm 120x120x63 mm 240
R014 Molded corner protector REF. 120-40 100x100x40 mm 120x120x80 mm 192
R286 Molded corner protector REF. 286 50x50x50 mm 64x64x64 mm 1000
R300 Molded corner protector REF. 300 55x55x55 mm 75x75x75 mm 1000
R425 Molded corner protector REF. 425 75x75x75 mm 105x105x105 mm 250
R490 Molded corner protector REF. 490 50x50x125 mm 65x65x140 mm 500
R626 Molded corner protector REF. 626 74x74x74 mm 90x90x90 mm 360
R780 Molded corner protector REF. 780 68x68x68 mm 90x90x90 mm 400
R980 Molded corner protector REF. 980 95x95x95 mm 115x115x115 mm 250
R985 Molded corner protector REF. 985 90x90x90 mm 115x115x115 mm 250
